Descriptions
• Developed based on Linux operating system, it is virus free and runs more safely and stably
• 4-core CPU processor, 1g main frequency, 17 seconds rapid boot, faster running speed
• Shutdown parameters are saved automatically, so you don't have to worry about data loss
• 18 channel signal input: 12 channel mic/line input, 2 groups of 3.5 lotus stereo input, 1 group of digital input: sound card,
MP3, AES digital input / output
• 10 channel signal output: Main output L, R, 6 aux1-6 auxiliary outputs, 1 headphone monitoring output
• Channel TFT LCD guided display, channel name and background color can be customized and edited (support
Chinese).
• MIC input gain adjustment (smooth digital gain, participate in saving to the scene)
• MIC input channel (linked) parity or AB joint debugging
• +48v phantom power supply (MIC channels can be opened and closed independently to participate in saving to the
scene)
• MIC input channel independent pad attenuation switch
• Each input channel has built-in voltage limiter, noise gate, high-low pass filter, 5-segment parameter equalization, time
delay, channel sound and image balance adjustment
• Fast copy function of channel parameters
• Input / output EQ on/off; Multifunction knob
• Each channel is equipped with multi-function menus, mute and monitoring
• All channels are equipped with 100mm electric pushers, signal and peak lights (14 Alps electric pushers)
• Input output independent physical pusher control
• The pusher function supports user-defined layers
• Two page turning buttons on the pusher layer (input page turning, output and effect fixed pusher, more convenient and
fast operation)
• 6 customizable physical keys; 6 DCA groups, 6 silent groups; Integrated feedback suppressor management
• The built-in signal generator (pink noise / positive Xuan wave / white noise) can be customized to output from any one or
more output channels
• Built in real-time spectrum RTA function (color editable)
• Integrated automatic mixing function
• AUX output (before / after the pusher) can be set
• Processing of each output channel: high-low pass filtering, 12 segment parameter equalization (GEQ supports
manipulation on the fader), compressor, delay, phase
• Stereo digital recording function
• Built in sound card (mobile phone, iPad, MP3, PC direct playback, recording)
• 4 quick scene call modes, 100 scene storage, customizable scene names, support Chinese input, seamless scene
switching, and no sound interruption
• Two independent DSP effectors are built locally, and a variety of effect modes are preset for direct use by users
• FX foot switch interface
• 12V output interface, external lighting equipment can be connected
• One click restore factory settings
• Support 232 central control; Support wired network port adjustment (or external router wireless adjustment)
• Multi operating system control software (IOS system, Android system, windows system)
• 7-inch 1024*600 high-definition capacitive touch screen
