6 zones audio mixer amplifier with USB BT SD Card Timer Tuner
Features
- Built-in MP3/Tuner/USB/SD card inputs
- 6 zones output with pre-amplifier, 6 channels @ 100V outputs
- 3 LINE& 2 MIC inputs with individual volume control
- Mute function, easy to insert priority broadcast
- Each zone with independent switch; bass and treble controlled
- With level indicators and 5-unit LED display
- Output short-circuit protection
Description
The Integrated Mixer Amplifier MP2708 is a 6 zones mix amplifier integrated with the functions of U disk, SD card, tuner, radio, Bt, zones and timer. With various functions, including song files playing, radio, schedule time etc. Touch screen control, all graphical interface, the operation is very simple and user-friendly. The device can meet the requirements of the users and can be widely applied. This product can be called 6 zone amp or Bt mixer amplifier.
Specification
|
Model |
MP2708 |
MP2715 |
MP2725 |
MP2735 |
MP2715 |
MP2765 |
|
Rated Output |
80W |
150W |
250W |
350W |
450W |
650W |
|
Output Method |
100V |
100V |
100V |
100V |
100V |
100V |
|
Harmonic Distortion |
<0.5% (1kHz, 1/3rated power) |
|||||
|
AUX OUT |
100Ω, 1V (0dBV) |
|||||
|
Input |
MIC: 600Ω; 10mV (±10% ) |
|||||
|
LINE: 10kΩ; 300mV (±10%), unbalanced |
||||||
|
LINE Freq. Resp. |
50Hz-18kHz (±3dB) |
|||||
|
MIC Freq. Resp. |
40Hz-16kHz (±3dB) |
|||||
|
Harmonic Distortion |
<0.5% (1kHz, 1/3 rated power) |
|||||
|
SNR |
MIC: 70dB |
|||||
|
LINE: 85dB |
||||||
|
Tone Adjustment |
BASS: ±10dB (100Hz) |
|||||
|
TREBLE: ±10dB (10kHz) |
||||||
|
Protection |
AC fuse, DC output protection, Overload protection |
|||||
|
Mute Function |
The microphone input can override other inputs (Attenuation 0 to -30dB) |
|||||
|
Power Supply |
AC220-240V/50-60Hz |
|||||
|
Power Consumption |
120W |
220W |
350W |
450W |
560W |
800W |
|
Dimension (mm) |
430×360×88 |
|||||
